Reliable Under Extreme Conditions
HIGH-PERFORMANCE BALL VALVES WITH METAL SEALING
Size
DN 15 - DN 350
Gas-Tight
Pressure max.
-1 bar to +400 bar
Temperature
-196°C to +600°C
Reliable Under Extreme Conditions
HIGH-PERFORMANCE BALL VALVES WITH METAL SEALING

Our fully metal-seated ball valves provide maximum safety and durability, even in the harshest industrial environments. Designed according to individual customer requirements, they withstand aggressive media, extreme temperatures, high pressures, and frequent switching cycles.

The metal-to-metal sealing between the ball and seat ensures an exceptionally long service life while significantly reducing maintenance effort. All ball valve types are available in a metal-seated version and can be optimally customized to meet specific operating conditions.

For existing systems, we offer tailor-made replacement solutions to ensure maximum process safety and efficiency.

INQUIRE NOW

Technical data

  • Application

    Applicable

    › High temperature and cryogenic

    › High pressure

    › Protection against abrasive wear, corrosion and chemical resistance

    › Thermal shock

    › High switching frequencies

    Targed industries:

    › Chemical

    › Pharmaceutical

    › Food

    › Petrochemical

    › Energy

    › Plastics

    › Oil and Gas

    › Cement and lubrication


  • Design

    Konstruktion

    Every single ATEC-ball valve can be designed
    with a metal seated ball system

    › Cavity free

    › Low sump area

    › Spring loaded sealing system

    › Full bore

    Ball valve version:

    › Bottom outlet

    › 2-way

    › Mulitway

    › Sample

    › Compact

    › Segment

  • Coating

    Coating

    Depending on the customer process, different coating processes are used:

    › High velocity oxygen fuel spraying (HVOF)

    › Spray- and – fuse method

    › Plasma- transferred welding method (PTA)

    › Laser cladding method

  • Material

    Metal to metal sealing system: base metal 1.4404/ Coating ATEC404

    O-Rings: Viton, EPDM, FEP-Viton or Graphitdichtringe

    Stem sealing: Packing out of PTFE or pure graphite with additional o-ring

    Coil springs: 1.4404

  • Special material

    Metal: austenite stainless steel (904L, 472/649, etc.) nickel- base alloy ( Hastelloy ® B, Hastelloy ® C, C276, Alloy 59 etc.) Duplex , Titanium, Monel ®, Inconel ®, Incoloy ®, Zirconium
    Further materials on request

    Further sealing: graphite, FEP coated Compounds, PFA coated Compounds, Kalrez, high- and low temperature - Kalrez, PFA/FEP coated stainless steel for cryogenic application, silver coated metallic o- and c-rings

    Conformity: USP, FDA, EFSA, ADI, 3-A, oil- and fat free
    Further conformity on request

    Stem sealing: PTFE chevron packing, high temperature packing
    Further materials on request

    Coil springs: Hastelloy ®
    Further materials on request

  • Downloads

    Downloads

    High velocity oxygen fuel spraying (HVOF): 168 | 251 | 231

    Spray- and - fuse method: 404 | 433 | 461 | 462 | 463
